A special edition of our Buffer and 3 Band EQ. Inverted color scheme and sliders give a new tactile and visual experience for a handy circuit everyone should have in their chain.
OBNE Utility 3 is an always on Buffer and switchable 3 Band EQ. The buffer is helpful for long cable setups or when using an overabundance of pedals. The EQ is helpful in tailoring frequencies to specific parts, guitar switches or using it as an always on EQ.
The Buffer is always on. The On/Off switch only activates/deactivates the 3 Band EQ.
Low : Slide up to boost and down to cut a 100 Hz Shelf
Mid : Slide up to boost and down to cut a 500 Hz Bell
High : Slide up to boost and down to cut a 2 KHz Shelf
An update on the popular modulation noisemaker pedal. Reflector V3 is a densely lush chorus coupled with three modes of modulation. This is a chorus with a bent, an ephemeral voice floating between aural dimensions.
Controls include Rate and Depth for the Chorus/Flanger/Vibrato speed, Mix for a balance between unaffected and affected signal and Modulate to add Pitch selection, Reverb wash amount or Flanger depth, depending on the mode. A three-way toggle switch allows the player to choose between Wrinkle Mode (A Vibrato-esque warble chorus with the added option of pitch selection, meaning the Modulate knob goes from one octave down to one octave up, with noon being close to pitch unity), Washed Mode (a simple lush chorus, Modulate control adds in a wash of Reverb pre Chorus effect) or Mirrors Mode (Detuned Chorus meets Flanger in which the Modulate knob controls the depth of the Flanger, while Rate corresponds to both the Flanger speed and the detuned Chorus speed).
The Reflector V3 features an expression out jack and clickless switching. The output level can be tweaked via an internal trimpot for boost, slight drop, or unity gain.
9VDC - 2.1mm negative center pin adapter.
60 mA draw.
- Toggle switch to select between three modes: Wrinkle (pitch shifted signal into
chorus), Washed (reverb into chorus), and Mirrors (resonant filter and chorus
- Mix control to go from fully dry (no affected signal) to fully wet (for true pitch
vibrato), with chorus sounds in between
- Rate and Depth control for the chorus, from slow and subtle to wildly wobbly
- Modulate control for pitch shift amount (octave down to octave up), reverb
blend (no reverb to full reverb), or filter depth
- Expression jack for external control of the Rate or Modulate parameter
- Internal trimpot to control output level
- Relay bypass switching and standard 9VDC center negative powerView full product details
Four isolated 150mA outputs for standard pedals, plus one 500mA output for high power devices . Link two 529 devices together to power up to ten effects pedals.
From the wall
If you have AC wall power available, just connect the 529 to the AC adapter with a USB cable. If you misplace the included AC adapter, you can use any USB wall power supply such as one the one from your smart phone or tablet.
From a battery
Power your pedal board from a portable USB battery pack, laptop, or a car’s USB charging port.
Home and studio
Connect the 529 to a computer or other desktop USB port.
Standard version includes USB wall power supply. Pro version includes USB wall power supply and a 10,000mA low profile rechargeable lithium battery.
