Description
This set features an underwound single coil pickup in the neck position, and a punchy overwound humbucker in the bridge position. The pairing of these two pickups together allows you to take your guitar from chime-y cleans to all out mid-forward assault with the flick of a switch. They even play well together in the middle position. Whether you play aggressive metal, or ambient reverb soaked post-shoe-worship, or both, this humbucker set has you covered.
DC Resistance:
Neck: 5.6kΩ
Bridge: 14.5kΩ
Magnet:
Neck: 0.187" Alnico 5 rod magnets.
Bridge: Polished Alnico 5 bar. This bar is shorter than the HB size magnet as a consequence of space.
Polarity:
Neck: South
Bridge: N/A.
Wiring
Neck: Black/Bare Wire - Ground; White Wire - Hot
Bridge (standard wiring): Green/Bare Wire - Ground; Black and White - solder together and heatshrink; Red wire - Hot.
